Serial communications using the STM32F042 Nucleo board

A previous post demonstrated semihosting which should be used to communicate with a host PC during unexpected fault conditions. For more general communications you can use the built-in serial port in the STLink-V2 interface. This is connected to USART2 in the STM32F042.
This simple program blinks the on-board LED and sends an ever increasing count (in HEX) to the host PC


/*
 * Blinky: Switch the MCU to highest speed and blink the LED attached
 * to port B, bit 3
*/


#include "stm32f042.h"

void delay(int);

void delay(int dly)
{
  while( dly--);
}

void initClock()
{
// This is potentially a dangerous function as it could
// result in a system with an invalid clock signal - result: a stuck system
        // Set the PLL up
        // First ensure PLL is disabled
        RCC_CR &= ~BIT24;
        while( (RCC_CR & BIT25)); // wait for PLL ready to be cleared
        // set PLL multiplier to 12 (yielding 48MHz)
  // Warning here: if system clock is greater than 24MHz then wait-state(s) need to be
        // inserted into Flash memory interface
        FLASH_ACR |= BIT0;
        FLASH_ACR &=~(BIT2 | BIT1);

        // Turn on FLASH prefetch buffer
        FLASH_ACR |= BIT4;
        RCC_CFGR &= ~(BIT21 | BIT20 | BIT19 | BIT18);
        RCC_CFGR |= (BIT21 | BIT19 );

        // Need to limit ADC clock to below 14MHz so will change ADC prescaler to 4
        RCC_CFGR |= BIT14;

// Do the following to push HSI clock out on PA8 (MCO)
// for measurement purposes.  Should be 8MHz or thereabouts (verified with oscilloscope)
/*
        RCC_CFGR |= ( BIT26 | BIT24 );
        RCC_AHBENR |= BIT17;
        GPIOA_MODER |= BIT17;
*/

        // and turn the PLL back on again
        RCC_CR |= BIT24;
        // set PLL as system clock source
        RCC_CFGR |= BIT1;
}

void configPins()
{
	// Power up PORTB
	RCC_AHBENR |= BIT18;

}

int main()
{
	unsigned count=0;
	initClock();
	initUART(9600);
	unsigned i=0;
	configPins();
	GPIOB_MODER |= BIT6; // make bit3  an output
	GPIOB_MODER &= ~BIT7; // make bit3  an output
	while(1)
	{
		printHex(count++);
		GPIOB_ODR |= BIT3;
		delay(200000);
		eputs("\r\n");
		GPIOB_ODR &= ~BIT3;
		delay(200000);

	}
	return 0;
}

Full code is available here:
http://eleceng.dit.ie/frank/arm/BareMetalSTM32F042Nucleo/index.html
